Grieve has introduced a large capacity bench oven used for vacuum bagging at a customer’s facility. The No. 1050 is a 400°F (204°C) oven with dimensions  measuring 36” W x 48” D x 36” H. 6.6 kW are installed in Incoloy sheathed tubular heating elements, while a 400 CFM, 1/3-HP recirculating blower provides airflow to the workload.

This Grieve oven features 2” insulated walls, six point vacuum manifold with individual shut-off valves, vacuum gauge and quick disconnect. Additional features include an aluminized steel exterior, Type 304, 2B finish stainless steel interior and an 80 CFM powered forced exhauster.

Controls on the No. 1050 include a digital programming temperature controller, manual reset excess temperature interlock with separate contactors and a recirculating blower airflow safety switch.

For more information, visit www.grievecorp.com.
