Key features:

•        A simplified packaging system for easier access to the device
•        Desiccant chamber securely holds the desiccant sachet and eliminate any contamination risk
•        Amcor’s Rayopeel seal technology provides clean peel for aseptic presentation
•        Multi-layer foil laminate provides transit resistance and barrier to gas, light and moisture
•        Production in certified clean room with state-of-the-art inspection equipment
•        2D barcoding for full traceability

Combination medical devices demand high performance packaging materials to ensure the sterility and shelf life of the product. The packaging system needs to provide barrier against light, moisture and oxygen to maintain the stability and efficacy of the Active Pharmaceutical Ingredients (API). Secony The pack also needs to be suitable for sterilization to deliver the device sterile at the point of use.

These two opposing requirements of breathability for sterilization and barrier can pose a challenge for packaging design. Stents, for example, are typically packaged in 2 separate pouches: the first to allow the ETO (ethylene oxide) sterilization process, and a secondary outer foil pouch with desiccant to preserve drug stability.

Amcor’s innovation is a single, multicompartment pouch with a breathable membrane separating the two chambers. The new Amcor Dual Chamber Pouch uses a high strength foil laminate that protects from light, moisture and oxygen ingress to support shelf life and drug efficacy. One side is peelable and allows aseptic presentation and easy access to the device. The second non-peelable chamber houses the desiccant sachet or other scavenging technologies.

The internal breathable vent allows gas exchange for the desiccant to maintain a controlled environment within the pouch. The separate chambers eliminate any risk of the desiccant encountering the sterile device and sterile field.  A porous header, that uses DuPont Tyvek is added to the pouch, which provides an easy method of ETO sterilization, after which the pouch is sealed, the header removed and the barrier pouch is ready for shipment.

Noemi Bertolino, vice president R&D EMEA at Amcor says, “To protect a combination sterile device with a therapeutic drug agent, we knew there were a lot of requirements to fulfil. The first objective was to create a pack design that was easy and intuitive to open and could be aseptically presented. The integrity of the drug’s effective dosage also had to be maintained.  To minimize the ingress of moisture vapor into the pouch, we created a vent towards the center of the inner film away from the seams. This solution maintains shelf life and minimizes any risk of contamination. Our Dual Chamber Pouch complies with necessary medical and safety regulations, in an efficient, simplified design.”

Amcor’s Dual Chamber pouch will be available in Europe from the company’s site in Sligo, Ireland, which is 100% focused on healthcare packaging. All production operates inside a certified cleanroom and uses the latest state-of-the-art inspection equipment for pouch making. Individual barcodes can be assigned to each pouch, providing full traceability, ensuring the highest standards of safety, quality and service are met for our customers.
