Bringing sweet tea and juice to the market requires palletizing the cases filled with respective bottles to be palletized for transportation to retail outlets. Due to their perishable nature, they are stored in cold rooms. A customer turned to Motion Controls Robotics Inc. (MCRI) to replace an inefficient existing system in which the vacuum cups and pumps utilized did not cope well with the average temperature in the cold room of 35°F (1.7°C). This caused vacuum cups to become rigid and pumps to not provide enough vacuum to hold cases leading to regular drop downs. A better system had to be found to handle cardboard cases weighing up to 42 lbs (19 kg).

Due to the wash-down process, any kind of area gripper consisting of closed-cell technical foam had to be excluded. Fork-style tools were also not an option due to limited workspace.

“With this information in mind, it was clear that the only possible solution would be cold-resistant silicone cups and high-quality, powerful vacuum pumps — a typical case for Piab vacuum solutions,” explains mechanical engineer Nathan Baker from MCRI. “Matt McClellan, technical specialist at Neff Group Distributors suggested we use the SX 12 ejector after further analysis on the most suitable pump with Piab’s technical expert, application engineer Oliver Lizotte.”


The robot picks up a pallet and places it on a roller conveyor with four mechanical clamps.
Image courtesy of Piab.


McClellan adds, “The SX 12 is the ejector Piab uses in their flagship piCOMPACT 23 SMART pump for high vacuum performance. It is based on their COAX vacuum generation technology. This ejector was particularly optimized for high reliability, flexibility, high vacuum flow and fast cycle times and is specifically recommended for palletizing solutions requiring large vacuum systems. Therefore, it seemed — and proved to be — the right solution for application case at hand at MCRI.” Oliver Lizotte agrees adding, “Thanks to its higher vacuum flow the SX12 ejector does not only offer a stronger holding force but is also dust and debris tolerant — an important feature in packaging applications dealing with cardboard boxes.”


Cold-resistant B75.20 silicone cups and powerful SX12 vacuum pumps from Piab provide a flawless gripping processes.
Image courtesy of Piab.


The COAX vacuum technology minimizes energy consumption and offers a safe and quick hold due to the high initial vacuum flow. COAX ejectors are up to twice as fast as other ejectors and deliver three times more volume flow than conventional vacuum ejectors with identical air consumption. The ejectors can deliver high performance even when the supply pressure is low or fluctuating. This has been proven in independent comparative tests at the Fraunhofer Institute for Machine Tools and Forming Technology IWU in Dresden. These have shown that the Piab ejectors require significantly less compressed air than ejectors from other manufacturers to achieve the same performance. Since they have no moving parts, they are also practically maintenance free and resistant to most environmental conditions such as cold. Their use accordingly reduces the costs for the provision of compressed air as well as downtimes for maintenance intervals and, thus, the overall handling costs.

Numerous in-house tests were conducted at MCRI to compare the SX12 holding force with that of the VGS 3010 generator using multiple different cups in both size and style. The result showed that the selection of the SX12 ejector is perfect. Simultaneously, cups of various material for cold resistance were tested by placing them for one week into a freezer and then conducting different stress and compression tests on the cups thereafter. Piab’s silicone B75.20 cup was the right one for this application also because these cups are suitable for height differences and slightly uneven or curved surfaces — particularly when several short bellow cups are combined in one lifting device. Piab’s policy of providing suction cups 30 days free of charge for testing gave system integrators an opportunity to thoroughly test the application and confirm the best product for each application.


two systems
After two layers of product the robot places an intermediate tier sheet on the stack.
Image courtesy of Piab.


The system starts with the robot picking up a pallet and placing it onto a roller conveyor. To do so, the end-of-arm-tool (EOAT) extends four mechanical clamps that grip underneath the pallet top. After the robot places the pallet on the roller conveyor the robot moves over to a plastic belt conveyor from where the cases filled with sweet tea or juice arrive to be palletized. A roll-up door that protects the operator from the running system opens the EOAT turns to the chain top conveyor. Using the silicone B75.20 Piab cups the robot’s EOAT grips a row of four boxes (nearly 170 lbs / kg) and places them on the pallet. After building two layers of product the robot grabs an intermediate tier sheet by extending four B50 multi-bellow silicone suction cups — also made of silicone — attached to VGS3010 pumps placed at the outer corners of the EOAT. The cups perform a slight lifting movement to easily separate the thin tier sheets. For lightweight tier sheets handling, the standard COAX technology-based ejector performs reliably.

Two of these palletizing cells are mirrored next to each other, both feeding a finished pallet stretch wrapper through a roll up safety door. The safety door prevents an operator from entering either palletizing cell.

Baker summarizes the improvements in the new palletizing cells, compared to the previous one. “With this case handling setup, we were able to gain an additional 10 lbs (4.5 kg) of holding force per main cup. In fact, we went from a system dropping nearly every case to a solution that picks any case — even wet cases or cases with cut tape and glue where the flaps are loose. The EOAT with Piab’s B75.20 suction cups and SX12 ejectors still makes the pick.”
